Threaded Check Valve, 01-666
Additional information
| Connection Type | Female thread acc. ISO 228/1 |
|---|---|
| Material Body | Stainless steel |
| Inner Parts | Stainless steel |
| Seat Sealing | PTFE |
| Temperature Range | -20°C to 200°C |
| Application Range | Cold water, Lubrication oil, Neutral gases, Petrol/Fuel Oil, Seawater, Warm water |
- Screwed bonnet
- Closed spring
- Vertical or horizontal installation
| Art. Nr. | DN | PN | L | H | ØD | kg |
| 01-666-1/4 | G1/4 | PN50 | 65 | 46 | 15 | 0.20 |
| 01-666-3/8 | G3/8 | PN50 | 65 | 46 | 15 | 0.20 |
| 01-666-1/2 | G1/2 | PN50 | 65 | 46 | 15 | 0.30 |
| 01-666-3/4 | G3/4 | PN50 | 80 | 68 | 20 | 0.40 |
| 01-666-1 | G1 | PN50 | 90 | 71 | 25 | 0.60 |
| 01-666-11/4 | G1-1/4 | PN50 | 105 | 74 | 32 | 0.90 |
| 01-666-11/2 | G1-1/2 | PN50 | 120 | 82 | 38 | 1.30 |
| 01-666-2 | G2 | PN50 | 140 | 95 | 50 | 2.00 |
| 01-666-21/2 | G2-1/2 | PN50 | 180 | 121 | 65 | 3.50 |
| 01-666-3 | G3 | PN50 | 200 | 138 | 80 | 5.00 |
