Threaded Angle Seat Globe Valve, 01-016
Additional information
| Connection Type | Female thread acc. ISO 228/1 |
|---|---|
| Material Body | Brass |
| Inner Parts | Brass |
| Seat Sealing | Soft sealing |
| Temperature Range | 0°C to 90°C |
- Screwed bonnet
- Without drain
| Art. Nr. | DN | PN | L | H | ØD | kg |
| 01-016-1/2 | G1/2 | PN10 | 65 | 70 | 50 | 0.30 |
| 01-016-3/4 | G3/4 | PN10 | 75 | 79 | 50 | 0.40 |
| 01-016-1 | G1 | PN10 | 90 | 98 | 60 | 0.60 |
| 01-016-11/4 | G1-1/4 | PN10 | 110 | 120 | 70 | 0.90 |
| 01-016-11/2 | G1-1/2 | PN10 | 120 | 137 | 80 | 1.20 |
| 01-016-2 | G2 | PN10 | 150 | 152 | 80 | 2.00 |
