Single Seated Float Valve, 01-613
Additional information
| Connection Type | Thread acc. to DIN ISO 228 |
|---|---|
| Material Body | Stainless steel |
| Inner Parts | Stainless steel |
| Seat Sealing | EPDM |
| Temperature Range | 0°C to 120°C |
- Closed design, valve lever for horizontally and vertically adjustable barrel-shaped float (stainless steel)
- For installation in depressureized vessels
- Valve closes when liquid level rises
- Body pressure-tight up to 10 bar
| Art. Nr. | DN | PN | L | kg |
| 01-613-3/8 | G3/8 | PN10 | 20 | 1.30 |
| 01-613-1/2 | G1/2 | PN10 | 20 | 1.30 |
| 01-613-3/4 | G3/4 | PN10 | 25 | 1.40 |
| 01-613-1 | G1 | PN10 | 28 | 1.90 |
| 01-613-11/4 | G1-1/4 | PN10 | 35 | 2.50 |
| 01-613-11/2 | G1-1/2 | PN10 | 40 | 3.60 |
| 01-613-2 | G2 | PN10 | 45 | 4.80 |
| 01-613-21/2 | G2-1/2 | PN10 | 55 | 8.00 |
| 01-613-3 | G3 | PN10 | 60 | 11.00 |
