Check Valve Screwed Ends, 01-086
Additional information
| Material Body | Gunmetal |
|---|---|
| Inner Parts | Brass |
| Seat Sealing | Metallic |
| Temperature Range | -10°C to 225°C |
- Screwed bonnet
- Locking Plate
- SDNR-plug
| Art. Nr. | DN | PN | L | H | ØD | kg |
| 01-086-6 | DN6 | PN40 | 78 | 110 | 60 | 0.40 |
| 01-086-8 | DN8 | PN40 | 82 | 110 | 60 | 0.40 |
| 01-086-10 | DN10 | PN40 | 88 | 110 | 60 | 0.40 |
| 01-086-12 | DN12 | PN40 | 104 | 130 | 80 | 0.70 |
| 01-086-16 | DN16 | PN40 | 112 | 130 | 80 | 0.80 |
| 01-086-20 | DN20 | PN40 | 134 | 150 | 100 | 1.30 |
| 01-086-25 | DN25 | PN40 | 146 | 150 | 100 | 1.50 |
| 01-086-32 | DN32 | PN40 | 168 | 180 | 120 | 2.30 |
